FV350 – Vertical Wrapping Machine

The vertical wrapping machines of the FV series are particularly suitable for wrapping all kinds of (long) products such as panels and bundles of bars, beams, profiles, pipes, cables, etc. Designed for easy operation, efficient and safe work. Adding value to any packaging process and working conditions. Equipped with two film trays, it can wrap up to 2x faster than any other wrapping machine, with only one real. Setting the right combination of ring rotation speed combined with automatic film attachment and cutting will give you a consistent well-wrapped package from start to finish. Whether you choose the semi-automatic or automatic version, in all cases you can control it manually or with a foot pedal.

Interested in this product? Contact us for a custom quote.

Technical parameters

ParameterValue
Diameter of the ring50-250 cm
Maximum speed50-350 rpm
EquipmentDouble roll film system / automatic double cutting system / colour touch screen / 6 packing programs / adjustable ring speed / adjustable feed speed / adjustable film tension / automatic start by photo cell
OptionsInfeed and outfeed pressure / roller conveyors - vertical rollers / top pressure - vertical rollers automatically / product bridge / remote assistance via Ethernet
FoilsWidth: 100 mm / Thickness: up to 30 my

Related products

Wrapping machine EXR-401 - horizontal, semi-automatic with film cutting

Wrapping machine EXR-401 - horizontal, semi-automatic with film cutting

Similar to EXR-301 with automatic film holding and cutting. For long items in stretch film.

product designation:700 009940
supply voltage:230V/50Hz
mass:290 kg
machine length:1246 mm
machine width:1084 mm
machine height:1512 mm
operating air pressure:6 - 7 bar
outer diameter of the winding cavity:76 mm
wrapping film - material:LDPE stretch
max. film width:76, 100, 125 mm
max. film thickness:19 - 35 my
conveyor width:560 mm
conveyor height:910 mm
min. package size item size (W x H):100 x 50 mm or 100 mm diameter
max. package size item (W x H):square 305 x 305 mm, rectangle 508 x 178 mm, circle diameter 330 mm
recommended length of package. of the subject:> 500 mm
max. foil diameter:178 mm
speed of the impeller:max. 100 rpm.
Wrapping machine EXR-201 - horizontal, semi-automatic with film cutting and welding

Wrapping machine EXR-201 - horizontal, semi-automatic with film cutting and welding

For long items in stretch film. With film cutting and welding. Stainless steel conveyors.

product designation:700 009941
supply voltage:230V/50Hz
installed power input:6 kW
mass:290 kg
machine length:1163 mm
machine width:1084 mm
machine height:1512 mm
operating air pressure:6 - 7 bar
outer diameter of the winding cavity:76 mm
wrapping film - material:LDPE stretch
max. film width:76, 100, 125 mm
max. film thickness:19 - 35 my
conveyor width:560 mm
conveyor height:910 mm
min. package size item size (W x H):100 x 50 mm or 100 mm diameter
max. package size item (W x H):square 305 x 305 mm, rectangle 508 x 178 mm, circle diameter 330 mm
recommended length of package. of the subject:> 500 mm
max. foil diameter:178 mm
speed of the impeller:max. 100 rpm.
Wrapping machine EXP-H2600 RONDO

Wrapping machine EXP-H2600 RONDO

Horizontal wrapping machine for large items (doors, windows, panels). Motorised input and output conveyor 3 m.

product designation:700 008459
supply voltage:400V/50Hz
installed power input:6 kW
wrapping film - material:LDPE stretch
max. film width:500 mm
max. film thickness:30 My
conveyor speed:4 m/min.
width of motor conveyor:1250 mm
conveyor height:900 mm
diameter of the orbital wreath:2600 mm
max. speed of the impeller:16 rpm
min. package size item size (W x H):60 x 1000 mm
max. package size item (W x H):1250 x 1000 mm
recommended length of package. of the subject:2500 - 13000 mm
machine width:3200 mm
machine height:3400 mm
Foam L-Profile L1, 30 mm x 30 mm, Length 2000 mm

Foam L-Profile L1, 30 mm x 30 mm, Length 2000 mm

Protective L-profile for corners and edges. 30 x 30 mm.
