FROMM P328 Smart - Battery Strapping Tool (12-16mm)

The P328S is a rugged intelligent digital strapping machine with full colour display.  Alerts when basic tape data, updates and service are needed (optional, wireless output)  Intelligent, multi-functional and easy to use colour touch screen, prevents water and dust from entering the device  3-in-1 tool with one-hand operation, easy choice of manual, semi-automatic or automatic operation  Setting and locking the correct tension force, speed and welding time at the touch of a finger  Tested to meet or exceed FROMM's high quality standards and customer expectations  Preset tape types with 10 configurable tape modes help set the tool up correctly  Durable design, easily recyclable, with dual "AlwaysGood" tape alignment guides  Easy tape insertion  Well balanced tool with extra finger protection for safe and good working conditions  Robust battery holder that holds a 5.0 Ah or even up to a 9.0 Ah battery  Brushless motor with motor temperature monitoring system. For extreme environments, an optional motor cooling fan is available  Easy maintenance, removing dust particles from the belt with compressed air Tapes are loaded simultaneously from the left side, tape guides are at the back and front of the taper. Tape force and welding time can be easily adjusted on the FULL COLOUR DISPLAY. Cooling time depends on welding time =˃ solid effective joint. The bevelled base plate allows very easy and smooth removal of the strapping machine - especially advantageous when strapping goods with small or round surfaces. The P328S has a well-balanced design, the plastic parts are made of reinforced polymers, the 5.0 Ah Li-Ion battery has the latest technology. The battery includes a charge indicator. Polyester (PET) and Polypropylene (PP) smooth and embossed tape types recommended Tape dimensions: 12.0-16.0 x 0.40-1.05 mm Weight: 4.3 kg (including 5.0 Ah battery) Machine size with battery: l 351 x w 134 x h 143 mm Weld type: Friction weld / bond strength corresponds to approx. 75% Tensioning speed: 49 - 174 mm/s Tensioning force: 250 - 2600 N - infinitely adjustable, depending on tape type Regulations:European safety regulations EN 415-8 Battery:Li-Ion 18 VDC / 5.0 Ah or 9.0 Ah ADVANTAGES:  Alert when needed for basic tape data, update and service (optional, wireless output)  Smart, multi-functional and easy to use color touch screen, prevents water and dust from entering the device  3-in-1 tool with one-hand operation, easy choice of manual, semi-automatic or automatic operation  Setting and locking the correct tension force, speed and welding time at the touch of a finger  Tested to meet or exceed FROMM's high quality standards and customer expectations  Preset tape types with 10 configurable tape modes help set the tool up correctly  Durable design, easily recyclable, with dual "AlwaysGood" tape alignment guides  Easy tape insertion  Well balanced tool with extra finger protection for safe and good working conditions  Robust battery holder that holds a 5.0 Ah or even up to a 9.0 Ah battery  Brushless motor with motor temperature monitoring system. For extreme environments, an optional motor cooling fan is available  Easy maintenance, removing dust particles from the belt with compressed air PARAMETERS: Recommended tape types Tape dimensions: 12.0-16.0 x 0.40-1.05 mm Weight: 4.3 kg (including 5.0 Ah battery) Machine size with battery: l 351 x w 134 x h 143 mm Weld type: Friction weld / bond strength corresponds to approx. 75% Tensioning speed: 49 - 174 mm/s Tensioning force: 250 - 2600 N - infinitely adjustable, depending on tape type Regulations:European safety regulations EN 415-8 Battery:Li-Ion 18 VDC / 5.0 Ah or 9.0 Ah

Interested in this product? Contact us for a custom quote.

Technical parameters

ParameterValue
Doporučené typy páskůPolyester (PET) a Polypropylén (PP) hladká a embosová
Rozměry pásky12.0–16.0 x 0.40–1.05 mm
Hmotnost4.3 kg (včetně 5.0 Ah baterie)
Velikost strojku s bateriíd 351 x š 134 x v 143 mm
Typ svaruFrikční svar / pevnost spojení odpovídá cca. 75%
Rychlost napínaní49 - 174 mm/s
Napínací síla250 - 2600 N - plynule nastavitelná, v závislosti na typu pásky
PředpisyEvropské bezpečnostní předpisy EN 415-8
BaterieLi-Ion 18 VDC / 5.0 Ah nebo 9.0 Ah
