Belt Conveyor FLEXITRANS

ATTENTION! This offer is not intended for countries: Germany, France, Great Britain, Netherlands, Sweden and Austria! This telescopic belt conveyor is designed for unloading or loading tyres or other piece goods from trucks or shipping containers. As standard, the conveyor consists of five synchronously driven belt conveyors that slide in or out under each other as required. The initial part of the conveyor is equipped with a lifting platform for one operator. The platform allows motorised height variation for the removal or storage of goods in different positions. For light goods use for both directions of transport, for heavier goods the conveyor is unidirectional. The conveyor is characterized by the possibility of height adjustment of the platform together with one side of the conveyor, motorized extension of the platform and infinitely variable belt speed control by frequency converter. It is equipped with running wheels, with brakes at the platform and at the end of the conveyor. Dimensions are given including the working platform. The advantages of this conveyor include: speeding up the unloading and loading process - greater efficiency saving on operating costs flexible use of the work area in the warehouse - once loading is complete the conveyor folds up and can be easily moved to another location smooth working process allows accurate planning of loading/unloading and minimises truck waiting time height adjustment allows less physical effort for the operator reduced risk of injury compared to manual loading/unloading low maintenance costs, ease of operation and maintenance FLEXITRANS may not be promoted, offered, marketed, sold or used in the following countries: Germany, France, Great Britain, the Netherlands, Sweden and Austria. FEIFER - kovovýroba, spol. s r.o. shall not be held liable for any violation of this provision and shall recover any damages from the specific violator.

Interested in this product? Contact us for a custom quote.

Technical parameters

ParameterValue
product designation600 000741
supply voltage400V/50Hz
installed power input2.2 kW
massapprox. 600 kg
load capacity kg/m of track25 kg
machine length7050 - 19000 mm
machine width1770 mm
machine height1110 - 1850 mm
active track width700 mm
conveyor speed10 - 28 m/min.
conveyor height660 - 1700 mm
conveyor length6270 - 18350 mm

Related products

Foam U-Profile U1, Inner Width 10 mm, Length 2000 mm
